Concept 2: Screws

Concept 2: Screws

0.290.84

1238 Screw, 6-lobe, 1/4-20 x 3/8; This is the handle hook screw on the Model C, D and E Indoor Rower.

1253 Screw, 6-lobe, 1/4-20 x 5/8, epoxy; Used in various places on the Model C, D and E Indoor Rower and the gray SkiErg manfactured between July 2009–July 2014.

1201 6-LOBE T-27 1/4-20 X 3/4 SS PATCHED; Used on the guide bracket of Model D Indoor Rowers, and on the rear leg of Model C and D Indoor Rowers.

1248 Screw 1/4 – 20 x 3/4 SS Buttonhead C/D/E; Used in various places on the Model C, D and E Indoor Rower and the gray SkiErg manfactured between July 2009–July 2014.

1231 Screw, 6-lobe, 1/4-20 x 1/2, epoxy; Used in various places on the Model C, D and E Indoor Rower.

2233 Screw 6 Lobe 1/4 – 20 x 3/4 SS Epoxy Patch; Used to attach front legs to the main body of the RowERG



Description

Used throughout the RowERG, Model C, D and E Indoor Rower, BikeERG and SkiERG

For master schematics of all models, visit Manuals and Schematics.

Additional information

Type

1201, 1231, 1238, 1248, 1253, 2233
